Innovative Heat Press Machine T-Shirts Garments Hot Stamping Machine
1.Product introduction of Heat Press Machine:
White ink heat transfer machine is applicable to: clothes, pants, hats, shoes, pillows,
cloth bags, aprons, washing water, reflective vests, volunteer vests and other personalized white ink heat transfer
The upgraded nozzle is better, high resolution, multi-color and durable, small nozzle hole, high precision, multiple nozzles, fast speed, Epson 3200 nozzle with 3PL minimum ink droplet printing precision is higher than the picture quality output is more exquisite, cost-effective nozzle overall performance increased by 50%
2.Technical parameters & Quotation of Heat Press Machine:
40CM Double Head White Ink Heat Transfer Printer
|
Model |
WM-THJ-A2 |
|
Printhead |
2Pcs Epson XP600/i1600/4720/i3200-A1 |
|
Ink Color |
colors (C, M,Y, K,W) |
|
Max.Feed Width |
430mm |
|
Max. Print Width |
420 mm/16(inch) |
|
Printing Speed |
4 Pass:5sqm/h |
|
Media Material |
PET Film |
|
Heating Device |
Front,middle and rear heating |
|
RIP Software |
Standard with Printfactory,Maintop,RIIN,PhotoPrint, CADlink for Optional |
|
Ink Supply System |
Automatic color ink supply system white ink circulation system |
|
Voltage |
110V/220V,50-60 HZ |
|
Power |
4KW |
|
Work Environment |
Temperature :18-32℃ Humidity :46-65%. |
|
Machine Size |
Printer :1100*510*625mm, 100Kg Powder Shaker:950*620*550mm, 50Kg |
|
Packing Size |
Printer:1080*650*660mm, 120Kg Powder Shaker:780*610*710mm, 60Kg |
60cm Double Head Black and White Heat Press Machine
|
Model |
WM-THJ600 |
|
|
Printhead |
2pcs of EPSON 3200 printheads |
2pcs Of EPSON F1080 printheads |
|
Printing Speed |
Double heads 10~12m²/h |
Double heads 7~9m²/h |
|
Inkjet Color
|
CMYK W (White and color come out at the same time) |
|
|
Ink Type |
Water-based pigment ink |
|
|
Ink Supply |
Continuous ink supply system |
|
|
Printing Width |
600mm |
|
|
Printing Media
|
Special printing film for hot stamping
|
|
|
Medium Transfer
|
Automatic film take-up system
|
|
|
Heating Device
|
Front, middle and rear three stages of heating
|
|
|
Transmission Interface
|
Gigabit network interface output
|
|
|
Power Supply
|
AC110V(±10%)50/60HZAC220V(±10%)50/60HZ
|
|
|
Work Environment
|
Temperature:15℃~25℃,Humidity:30%~65%RH
|
|
|
Machine Size
|
Printer: 1600*750*1510mm(L*W*H) |
Double heads size and rated power of the powdershaker: 1213*733*1050mm 2.8KW 110V/25A 220V/12.5A |
|
Wooden Case Size
|
1670*760*670mm(L*W*H) |
1290*910*1200mm |
|
Machine weight |
125kg |
105kg(double heads) |
4-head White Ink Heat Transfer Printer
|
Model |
WM-THJ604 |
|
|
Printhead and Quantity |
4720/I3200-A1 4pcs |
Retractable Media Width：0-600mm |
|
Printing Speed |
4Pass:22㎡/h 6Pass: 15㎡/h |
Fan Control： Shake powder control, dusting control, direction and quantity control |
|
Printing Width |
0.6M |
/ |
|
Media Type |
Petfilm |
Rewinding Function: Automatic induction winding |
|
RIP Software |
Digital offset heat transfer die Standard with Printfactory, Maintop, PhotoPrint, CADlink for Optional |
Heating and Drying Function: Efficient and powerful drying and curing |
|
Temperature/Humidity |
Humidity:45-65% Temperature:20-30°C |
Electrical Parameters: Rated voltage:220V Rated current:40A Rated power:6.8KW Energy consumption:3KW-6.8KW |
|
Machine Dimension |
1670mm*815mm*1600mm |
2305mm*1092mm 1102mm |
|
Package Dimension |
2025mm*840mm*740mm |
2400mm*1120mm* 1140mm |
|
Net Weight |
150KG |
210KG |
|
Gross Weight |
210KG |
300KG |
|
Power Voltage |
220V |
220V |
|
Power |
350W |
680W |
Pressing Machine
|
Model |
WM-SYT-01 |
WM-SYT-02 |
WM-SYT-03 |
WM-SYT-04 |
WM-DYT1 |
WM-DYT2 |
|
Printing Size |
38*38CM |
40*60CM |
50*70CM |
60*80CM |
38*38CM |
40*60CM |
|
Voltage
|
220V/110V |
220V/110V |
220V/110V |
220V/110V |
220V/110V |
220V/110V |
|
Power
|
2.0KW |
2.2KW |
5.0KW |
6.0KW |
2.8KW |
3.5KW |
|
Temperature Range
|
0-399℃ |
0-399℃ |
0-399℃ |
0-399℃ |
0-399℃ |
|
|
Time Range |
0-999S |
0-999S |
0-999S |
0-999S |
10-15 minutes |
|
|
Weight
|
30KG |
45KG |
79KG |
66 |
150 |
163 |
|
Packaging Size(CM) |
75*65*40 |
80*75*50 |
90*90*62 |
117*74*50 |
137*75*95 |
|
Other Consumable Products
|
Model |
|
WM-MS01 I
$
